LCD 1602 and Pi – Part 2: Configuring and Orange Pi for 1602 LCD with i2c

Part 1 is here: http://www.mintrix.net/blog/2019/08/07/1602-lcd-displaying-interface-ip-addresses-for-a-headless-raspberry-pi-part-1/

So previously, I talked about how to set up a Raspberry Pi with LCD 1602 via i2c. It was extremely easy on Raspian. you simply have to enable the i2c support and boom you can run the python script and it works. However, Orange Pi is a clone of RPi and it doesn’t run Raspbian, so it takes few more steps to get that working. So here is the step by step on how to set the sucker up and at the end of the day, it should be pretty much exactly the same as the Raspberry Pi setup.

TL; DR: just watch the video at the end….

So just follow these simple step

STEP 1: apt-get install -y python-smbus i2c-tools python-dev
Download the required modules.
python-smbus
i2c-tools
python-dev

These files are necessary for the python script to run in the near future.

STEP 2: edit /etc/modules file with “nano /etc/modules
add “i2c-dev” in the file no quotes!!

STEP 3: edit /boot/armbianEnv.txt file with “nano /boot/armbianEnv.txt
add “overlays=i2c0 i2c1 i2c2

By default, I2C buses are not enabled, except for the s_i2c .
To enable other i2C buses, you need to edit the overlays in the /boot/armbianEnv.txt
overlays=i2c0 i2c1 i2c2
Then, reboot. After you will have 4 buses in /dev/i2c-*.
You can then scan the buses with “i2cdetect -y n”, where “n” is the bus number.

ref: https://forum.armbian.com/topic/4154-not-armbian-orangepi-zeroplus-h5-i2c/

STEP 4: reboot and test io
reboot

After OrangePi reboots, you will have 4 buses in /dev/i2c-*.
You can then scan the buses with “i2cdetect -y n”, where “n” is the bus number.

i2cdetect -y 0
i2cdetect -y 1

STEP 5: test with script
Download the lcd_i2c python script from Matt Hawkins.
type :
wget https://bitbucket.org/MattHawkinsUK/rpispy-misc/raw/master/python/lcd_i2c.py

and run the script by typing

python lcd_i2c.py

woo hoo!!! you are done!!!

References:

https://www.abelectronics.co.uk/kb/article/1061/i2c–smbus-and-armbian-linux

https://forum.armbian.com/topic/4377-using-16×2-1602-lcd-with-i2c-connector-with-orange-pi-pc/

Cremation

So yesterday, I saw my father for the very last time. I witnessed my fathers cremation. I saw my fathers body laying there peacefully. My mother cried, she told me that my father is leaving us. I told her that My father already left us last week, and he is off at a better place and we gave him a proper sendoff already. This is just the body that we need to send off so that dad can rest. I may sound very crude, but I believe that it is true we have to close this chapter and move on to the next. I miss my father very much I think about him everywhere I look. But the fact is, there is nothing I can do to bring him back. There still a lot of things to do after this. I still have to help my mom situate everything and take my dad to his final resting place. 2019 has been a really tough year.

Dad’s funeral

Yesterday was a busy day. It was my dad’s funeral. The day started very very early, Dad’s viewing was at 9:00 am and the Mass was at 10:00. Flowers came in around 8:10 and Dad arrived at 8:30.

This was the first time seeing my father after he left us and it felt strange. He looks really peaceful. He almost looks like he was in a deep sleep. Mom cried after seeing him, saying that it doesn’t even look like my father. But I thought they did a pretty good job.

Through out 9-10, people trickled in. And flowers came in from friends and family. Including many flowers from friends from Auburn who could not attend and from Tuskegee University where my father taught for many years, and from Gigamon.

It was a beautiful mass!! We had a Vietnamese choir and a number of local Chinese parishioners attending and supporting the mass. The Mass was entirely in Chinese which was pretty cool. This was really good for my mom as well.

All and all, I thought the funeral went pretty well for pulling everything together in a such a short time. There were amazing people at this church!! Thank you everyone !!!

It was great to see all our friends and families together, even though it is at such a difficult time, but it also shows the celebration of life that my father lived and inspired.

Good bye Dad

Yesterday 8/14/2019 at 4:35pm, my father left us. He has been fighting cancer for the last 9 month. Initially, treatment went pretty well, but last 3 months the conditions turned for the worst. The last month was really tough for my father and my family. My dad went from a fully functioning person to completely bedbound. For the last few weeks, my dad spend his remaining time at my home on hospice. We try to do our best to make sure he was comfortable. There were good days and there were bad days, but it was a constant emotional stress on my mom.

Yesterday, for the first time in my life I saw the end of life for another human being. That was my father.

Yesterday I think I finally grown up. Witnessing my father’s passing and seeing my father’s life slipping away from his eyes and seeing him taken away to the funeral home. It really makes one think of what really important and continue to cherish all that we take for granted.

My dad was and extremely brilliant man who knows how to live life. Professionally, my dad was an excellent professor who inspired many in the field of computer science and information assurance. (Including myself) In private, my father was a great husband, a wonderful father. My dad loves fishing. He taught me everything I know about fishing , how to tie a hook, how to hook a live minnow, how to dock a boat on a trailer.

My dad was also a very handy person and always taught me to think like an engineer. I remember when we built our back deck together and how he taught me how to use a hammer and power drill properly. I also remember his love for his garden and his pond, where my mom and dad built the pond by hand, one stone at a time.

My father was an excellent billiards player and even close to winning few regional tourneys.

Finally, my father loved seafood and different type of exotic and wonderful fruits. He never ate too much but he knows what’s good!! My love for good food and fruits are a direct influence from him. In the end, it was really tough for him to not being able to eat.

My dad lived a short but very interesting 71 years. Growing up in Taiwan, he had a wonderful career as an electrical engineer,but gave it up to immigrating to the US in the 80’s to get his Ph. D and to give his kids new and wonderful opportunities. I believe he made a direct positive impact on many life’s, especially Min-Jye and mine.

We will all miss you, Dr Chen!!!

I miss you Dad!!!

LCD 1602 and Pi – Part 1: 1602 LCD displaying Interface IP addresses for a headless Raspberry Pi

So I’ve been working on some projects for work and I dug into my collection of parts and pulled out my OG raspberry pi’s (RPi). I am using them as endpoints for a proof of concept project for OT visibility. But since they are all headless, (meaning there are no monitors or keyboards for input and output), the RPi’s just looks boring and also, I have to dig through the DHCP server log to see what IP address the RPi grabbed.

So I thought to myself, there got to be a better way. Since there are a bunch of these GPIO (General Purpose Input /Output) pins on the RPi’s, and there are some display connectors, I have a few options.

  1. get a touch screen for the Raspberry Pi and go from there.
  2. Maybe a simple LED?
  3. Maybe some LCD displays?

Option 1 is too much of an overkill. Option 2 just doesn’t show enough information. Option 3 seems like it could work. So I started to research on using LCDs.

Here is what I’ve found and Yes it is super easy. So I found these 16×02 LCD displays. So there are two ways to output to these displays, you can use multiple GPIO pins and connect them to the 16×02 displays or you can use a I2C chip and connect to the LCD display using only 4 pins. This includes 5v Vcc, GND, SDA (Serial Data), SCL (Serial Clock). So what is I2C?

I2C stands for Inter-IC, it is a serial communication protocol. It is very handy. So instead of doing a bunch of soldering and breadboarding, I was able to connect it up and get everything running in 5 minutes. Don’t believe me take a look below.

So yes… under 5 minutes is just the physical wiring but actually configuring the SD card take a little bit more time. Which I can go into a bit more in my next post.

Materials used:
1602 Serial Blue LCD Module Board with i2c – https://amzn.to/2GOdvz6
Breadboard Jumper Wire – https://amzn.to/2YP4Q9C
Board standoff assortment kit – https://amzn.to/2GMlqNa
Raspberry Pi (model 3 b – not the same as in the video) – https://amzn.to/2YLP1wo
Small wifi adapter for pi – https://amzn.to/2Kf9BkW

Feel free to let me know if you have any questions.

Part 2: is here
http://www.mintrix.net/blog/2019/08/21/lcd-1602-and-pi-part-2-configuring-and-orange-pi-for-1602-lcd-with-i2c/
